Door Frame Metal Detector (Auto tune)

We are the prominent Manufacturer and Supplier of Door Frame Metal Detector (Auto tune) from Delhi (India). Fabricated in accordance with the international quality standards, our Single Zone Walk Through Metal Detector detects hidden ferrous and non-ferrous metals on the body of a person. Quick installation, LED based 10 step bar graph indication and automatic zero adjustment are the highlights of our Door Frame Metal Detector (Auto tune). With us, stay assured of nominal prices and timely delivery.

Details :

  • Door Frame Metal Detector (Auto tune)
  • Metscan Auto Tune Most Reliable & Economical
  • Metscan made reliable single piece walk through metal detector
  • It has been developed to detect clandestine ferrous and non-ferrous metals on the body of a person when asked to pass through the door frame


Salient Features :

  • Low cost single zone detector.
  • Quick Installation no training required.
  • Automatic zero adjustment.
  • 10 step bar graph indication LED Based.
  • Ignores external metals.


Physical Parameters :

  • Control Unit : Built in
  • Ramp : Covered with synthetic carpet for long life.
  • Passage : 1950mm x 750mm
  • Overall Dimension : 2100mm x 825mm x 300mm

Principal : The operation of metal detector is based upon the principals of electromagnetic induction.

Technical Parameters :

  • 10 levels of sensitivity.
  • CV & CC SMPS power supply for use with 90 V to 270 V.
  • Polyphonic tone through audio speaker.
  • Built in full function battery back-up for over 12 hours.
  • Detect all ferrous & Non-ferrous metals.
  • Intelligent people counters for entry, exit and algebraic sum. (Optional)


Size Mulitsizes
Type Door Frame Metal Detector
Material Aluminum
Weight 0-50kg
Color Black
Voltage 110V
Usage Detect Knife And Gun
Power Source Battery
Features Built In Speaker
Warranty 1year
Sound Beep
